Product
HX-1710P 350-1700nm Benchtop Wide-Spectral Detector
Based on dispersive spectroscopy hyperspectral imaging technology, the HX-1710P Benchtop Wide-Spectral Detector covers a measurable spectral range of 350–1700 nm and supports two acquisition modes: transmission and reflection. Composed of two parts—the detection chamber and the touchscreen—the benchtop wide-spectral detector integrates a spectrometer, a light source, and an acquisition control computer inside. It boasts prominent advantages such as fast speed, high accuracy, simple operation, and portability, which can meet users' detection needs for a wide spectral range.

Application Fields

1. Materials Science

Component Analysis: Detect the chemical composition or optical properties of materials, such as semiconductors, thin films, coatings, etc.

Uniformity Detection: Analyze the uniformity of spectral reflection or transmission on the material surface.

2. Agriculture and Food

Agricultural Product Quality Inspection: Detection of sugar content, moisture, ripeness, or diseases in fruits and vegetables.

Food Authenticity Identification: Adulteration analysis of foods such as honey and edible oil.

3. Biology and Medicine

Biological Tissue Detection: Detection of photosynthetic efficiency or pathological changes in plant leaves, for example.

Pharmaceutical Quality Control: Detection of the component uniformity of tablets or the light transmittance of packaging materials.

4. Environmental Monitoring

Pollutant Detection: Spectral characteristic analysis of specific substances (such as oil stains, heavy metals) in water or air.

Mineral Identification: Identification of mineral components in soil or rocks.

5. Industrial Manufacturing

Plastic/Textile Classification: Distinguish material types or color consistency through spectral characteristics.

Printed Product Inspection: Rapid evaluation of ink components or printing quality.

Specifications

设备型号

模块

TECHNICAL SPECIFICATIONS

HX-1710P

光谱

光谱范围:350-1700nm

光谱分辨率:≤2nm(350-900nm),≤10nm(900-1700nm)

光源

内置透反射全谱段光源

样品尺寸

直径≤125px,厚度≤8mm

主机

全电容触控显示屏

内置存储容量:512GB(最高支持2TB)

接口

USB 3.0 * 2

电气参数

电源:AC 220V~ 50Hz

最大功耗:≤35W

环境参数

工作温度0℃~50℃,储存温度-20~70℃

湿度20%~95%RH(无冷凝)

其他

尺寸:275*200*161mm

重量:约3kg
