Product
HX-P17 NIR(900-1700nm ) handheld Spectroscopy Plastic Analyzer
The HX-P17 handheld near-infrared (NIR) spectroscopy analyzer adopts advanced spectral detection technology, covering a spectral range of 900–1700 nm, and is suitable for rapid compositional analysis of various plastic materials. The instrument integrates a high-performance spectral detector, a stable light source, and an intuitive touch operation interface. With its compact design and lightweight construction, it is convenient for rapid on-site testing. The HX-P17 features high sensitivity and high resolution, enabling rapid acquisition of precise spectral data to help users identify plastic types in real time. Whether for waste plastic classification, material recycling, or product quality inspection, it delivers efficient and reliable support, providing users with accurate and rapid analytical solutions.

Application Fields

Waste Plastic Classification, Material Recycling,

Product Quality Inspection

Functional Features

Specifications

设备型号

TECHNICAL SPECIFICATIONS

HX-P17

光谱范围

900-1700 nm

识别塑料种类

ABS, PE, PET, POM, PP, PVC(持续更新)

测量时间

1~3s

光源功率

1.4 W

整机功率

40 W

使用温度

0-50 ℃

电池容量

5000mAh

电池续航

2 h

充电电压

16.8V

重量

1.4 kg

尺寸

270mm*205mm*98mm
